Tank mounted return filter, element oil flow internal to external. Working pressure up to 10 bar (145 psi), flow rates up to 3000 l/min (793 gpm).
Heavy duty high flow rate design to be incorporated into a "Dirt Box" arrangement within the tank to minimize external dimensions and provide multiple return connectins from the hydraulic system. "Inside to Outside" oil flow element design retains captured contamination within the element replacing the element and preventing contamination back into the tank.
See the relevant table for fluid compatibility.
